Failure Modes and Effects Analysis (FMEA) / Failure Modes, Effects and Criticality Analysis (FMECA)

$20.00

There are very few reliability design analysis tools that are as widely practiced as Failure Modes and Effects Analysis (FMEA) or its derivative, the Failure Modes, Effects and Criticality Analysis (FMECA). The FMEA/FMECA is a tool by which a design is analyzed to identify all credible potential ways that the building blocks of a design can fail, and the impact that these failures can have on the product or system. The process begins by identifying the building blocks (for example, individual components or functional blocks), then enumerating the functional requirements for each block, and finally listing the effect(s) of failure on both the local and higher-level assemblies until the impacts on the final product or system are projected. For this reason, the analysis is referred to as a “bottom-up” approach.

*Available as a PDF Download File Only

SKU: RELEASE-FMEA Category: Tag:

Product Description

The series name has a double meaning:
(1) the spelling of the name r-e-l-e-a-s-e indicates that the series is intended to “release“ the non-expert down the path to reliable products and
(2) the complementary terms “REL” with “ease”, implying the series goal of “reliability made easy.”

Of course, reliability success is seldom easy, requiring expertise and tailoring with tradeoffs addressing life-cycle costs and other issues, but we hope that the series will help those not familiar with reliability practices understand the basics.

While it is unlikely that the reader will become an instant expert in reliability by reading the RELease guides, it is likely that he/she will gain a better appreciation of the basic tools that lead to designing and building reliability into products and systems. The number of pages in each guide is intentionally limited to address only the basics, with comprehensive authoritative references listed for those wanting to know more. The initial set of guides will be continuously expanded in the future. Please let us know how the series can be improved to meet your needs in introducing reliability to the non-expert, or suggest other topics you would like to see developed.

Additional information

File Type:

PDF
Author:

Daniel Gonzalez
ISBN:

978-1-933904-50-4
Pages:

20
Publication Date:

July 2013

Table of Contents

1. What is an FMEA/FMECA 2
2. FMEA/FMECA Terminology 4
  2.1. Failure Modes 5
3. Performing an FMEA/FMECA 6
  3.1. Before You Begin 6
  3.2. FMEA/FMECA tools 8
  3.3. Performing an FMEA/FMECA per MIL-STD-1629A 8
  3.4. Performing the Criticality Analysis (CA) per MIL-STD-1629A 11
  3.5. Performing an FMEA/FMECA per SAE and IEC Standards 14
  3.6. Key Differences Between the MIL-STD-1629A and SAE/IEC Approaches 17
  3.7. The Process FMEA 18
  3.8. FMEA/FMECA Limitations 18
4. Details 19
5. For More Information 20

Copyright Information

Copyright © 2013 by Quanterion Solutions Incorporated.

These publications were developed by Quanterion Solutions Incorporated, and the materials contained within are protected by U.S. Copyright Law and may not be copied, automated, resold or re-distributed to multiple users without the express written permission of Quanterion Solutions Incorporated.  If copying, automating, reselling or re-distribution of this copyrighted material is desired, please contact 877.808.0097 (toll free) or 315.732.0097 for licensing information.
